Cadillac STS I (2004-2007) left rear door latch assembly left rear window switch Wiring diagram
This page shows the only wiring diagram for the component.left rear door latch assembly left rear window switch, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear door latch assembly left rear window switch (1 of 1)
BLK WIRE
CONTROL MODULE
DATA LINK CONNECTOR (DLC)
DRIVER BACK HEATED SEAT ELEMENT
DRIVER CUSHION COOLED SEAT BLOWER MOTOR
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER DOOR LOCK SWITCH LEFT REAR DOOR MODULE (LRDM)
DRIVER DOOR SWITCH ASSEMBLY (DDSA)
DRIVER SEAT ADJUSTER SWITCH
DRIVER WINDOW MOTOR
HEAD UP DISPLAY (HUD)
HEATED STEERING WHEEL
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
INTERIOR REAR COMPARTMENT LID RELEASE SWITCH
LEFT FRONT SEAT BELT SWITCH
LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR WINDOW SWITCH
LEFT REAR WINDOW MOTOR
LEFT STEERING WHEEL CONTROLS
MEMORY SEAT MODULE (MSM)
NCA WIRE
PASSENGER BACK COOLED SEAT BLOWER MOTOR
PASSENGER BACK HEATED SEAT ELEMENT
PASSENGER CLIMATE CONTROL SEAT MODULE
PASSENGER CUSHION COOLED SEAT BLOWER MOTOR
PASSENGER CUSHION HEATED SEAT ELEMENT
PASSENGER LUMBAR ADJUSTER SWITCH
PASSENGER SEAT ADJUSTER SWITCH
RIGHT FRONT SEAT BELT SWITCH
RIGHT STEERING WHEEL CONTROLS
SPLICE PACK
TURN SIGNAL/ MULTIFUNCTION SWITCH
W/ POWER LUMBAR SEAT
W/O FRONT HEATER SEAT
W/O POWER LUMBAR SEAT
WHT WIRE
Go to component -> Ground distribution circuit (3 of 5) -> LEFT REAR DOOR LATCH ASSEMBLY LEFT REAR WINDOW SWITCH
