Cadillac STS I (2004-2007) left horiz horiz pos sens Wiring diagrams

1 2 3 LOW SPD GMLAN SERIAL DATA BAT POS VOLTAGE 1 2 5 LFT MIR MTR DN CTRL LFT MIR MTR UP/RT CTRL LFT MIR MTR LFT CTRL BLK WIRE BLK/WHT WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/BLK WIRE DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR) DRIVER DR MOD FUSE DRIVER OUTSIDE REARVIEW MIRROR DRVR VERT POS SENS SIG LOW REF DRVR HORIZ POS SENS SIG FEED GROUND HORIZ MOTOR HORIZ POS SENSOR HOT AT ALL TIMES LEFT HORIZ HORIZ POS SENS LEFT LOGIC LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT) LT BLU/BLK WIRE MIRROR SWITCHES DRIVER DOOR SWITCH ASSEMBLY (DDSA) PPL/BLK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT RIGHT HORIZ RTN SEL LEFT SEL RIGHT VERT DOWN VERT MOTOR VERT POS SENS VERT POS SENSOR VERT UP W/ INFOTAINMENT SYSTEM 012, 014, 015 WHT WIRE YEL WIRE

1 2 3 LOW SPD GMLAN SERIAL DATA BAT POS VOLTAGE 1 2 5 RT MIR MTR DN CTRL RT MIR MTR UP/RT CTRL PASS MIR MTR LFT CTRL 2 7 9 BAT POS VOLTAGE LOW SPD GMLAN SERIAL DATA GND BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DRIVER DOOR MODULE (DDM) (INSIDE DRIVER DOOR) DRIVER DR MOD FUSE FEED FRONT PASSENGER DOOR MODULE (FPDM) (INSIDE RIGHT FRONT DOOR) GROUND GRY WIRE HORIZ MOTOR HORIZ POS SENSOR HOT AT ALL TIMES LEFT HORIZ HORIZ POS SENS LEFT LOGIC LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT) LT BLU/BLK WIRE LT GRN WIRE MIRROR SWITCHES DRIVER DOOR SWITCH ASSEMBLY (DDSA) PASS VERT POS SENS SIG LOW REF PASS HORIZ POS SENS SIG PASSENGER OUTSIDE REARVIEW MIRROR PPL/WHT WIRE RED WIRE RED/WHT WIRE RIGHT RIGHT HORIZ RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT) RT FRT DR MOD FUSE RTN SEL LEFT SEL RIGHT VERT DOWN VERT MOTOR VERT POS SENS VERT POS SENSOR VERT UP W/ INFOTAINMENT SYSTEM 012, 014, 015 WHT WIRE YEL WIRE
