Cadillac STS I (2004-2007) ipm/ aldl fuse volt check fuse Wiring diagram
This page shows the only wiring diagram for the component.ipm/ aldl fuse volt check fuse, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ipm/ aldl fuse volt check fuse (1 of 1)
1 5 12 SUPPLY VOLTAGE STOP LAMP SW SIGN HAZARD SW SIGN
2 4 5 8 6 BATTERY GROUND LR STOP/TURN SUPPLY VOL GROUND RR STOP/TURN SUPPLY VOL
3 13 LR TURN SIGN SUPPLY VOL RR TURN SIGN SUPPLY VOL
4 1 2 SUPPLY VOLTAGE SIGNAL GROUND
AUTO HEAD PARK
BACK LIGHT LAMP
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
HAZARD SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL MODULE (RIGHT SIDE OF DASH BEHIND GLOVE BOX)
IPM/ ALDL FUSE VOLT CHECK FUSE
LEFT FRONT TURN SIGNAL/ FOG LAMP ASSEMBLY LEFT FRONT TURN SIGNAL LAMP
LEFT LICENSE LAMP RIGHT LICENSE LAMP
LEFT REPEATER LAMP
LEFT TURN SIGNAL FUSE RIM FUSE
LEFT TURN SIGNAL IND
LIC/IPM FUSE
LOGIC LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT BLU/WHT WIRE
LT DK
LT LT
OFF
PARK LAMP RELAY
PARK LAMP RLY CTRL
REAR INTEGRATION MODULE (IN LEFT SIDE OF REAR COMPT, UNDER REAR SHELF)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT TURN SIGNAL/ FOG LAMP ASSEMBLY RIGHT FRONT TURN SIGNAL LAMP
RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT)
RIGHT REPEATER LAMP
RIGHT TURN SIGNAL IND
SPLICE PACK
TILT/ LK LMP/ CLM RELAY COILS FUSE
TO UNDERHOOD FUSE BLOCK (LT PARK FUSE,
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENG COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> IPM/ ALDL FUSE VOLT CHECK FUSE
