Cadillac STS I (2004-2007) i/p dimmer sw low Wiring diagram
This page shows the only wiring diagram for the component.i/p dimmer sw low, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram i/p dimmer sw low (1 of 1)
AJAR
AUTO ON
BLK WIRE
COMPUTER DATA LINES SYSTEM
COURTESY LAMP HIGH
COURTESY LAMP LOW
COURTESY LAMP SW ON
DK GRN WIRE
DRIVER DOOR MODULE (DDM) (IN DOOR)
FRONT PASSENGER DOOR MODULE (FPDM) (IN DOOR)
GMLAN SERIAL DATA
GRY WIRE
GRY/BLK WIRE
I/P DIMMER SW LOW
I/P DIMMER SWITCH
INSTRUMENT PANEL MODULE (IPM) (BEHIND RIGHT SIDE OF DASH)
LEFT FRONT DOOR COURTESY LAMP
LEFT FRONT DOOR LATCH ASSEMBLY
LEFT REAR DOOR MODULE (LRDM) (IN DOOR)
LF DOOR AJAR
LR DOOR AJAR
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RF DOOR AJAR
RIGHT FRONT DOOR COURTESY LAMP
RIGHT FRONT DOOR LATCH ASSEMBLY
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR DOOR MODULE (RRDM) (IN DOOR)
RR DOOR AJAR
TAN WIRE
TAN/WHT WIRE
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> I/P DIMMER SW LOW
