Cadillac STS I (2004-2007) (in passenger door harn, 32 cm from front passenger window motor connector Wiring diagram
This page shows the only wiring diagram for the component.(in passenger door harn, 32 cm from front passenger window motor connector, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in passenger door harn, 32 cm from front passenger window motor connector (1 of 1)
A/T SHIFT LEVER ASSEMBLY
ACCESSORY RELAY
AIR QUALITY SENSOR
BLK WIRE
BLK/WHT WIRE
BLOWER CONTROLLER
CONSOLE AUXILIARY POWER OUTLET
DISTANCE SENSING CRUISE CONTROL MODULE
FRONT AUXILIARY POWER OUTLET
FRONT PASSENGER DOOR MODULE
FRONT PASSENGER WINDOW MOTOR
FRONT PASSENGER WINDOW SWITCH
HAZARD SWITCH
HOOD AJAR SWITCH
HORN ASSEMBLY
I/P COMPARTMENT LAMP SWITCH HVAC CONTROL MODULE
IGN 1 RELAY
IGNITION MODE SWITCH
INSTRUMENT PANEL MODULE (IPM)
LEFT FRONT CORNERING/ SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL/ FOG LAMP ASSEMBLY
LEFT HEADLAMP
LEFT REPEATER LAMP
NCA WIRE
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER DOOR LOCK SWITCH
REAR AUXILIARY HVAC CONTROL MODULE REAR AUXILIARY POWER OUTLET
RIGHT COOLING FAN
RIGHT FRONT CORNERING/ SIDE MARKER LAMP
RIGHT FRONT DOOR HANDLE SWITCH
RIGHT FRONT TURN SIGNAL/ FOG LAMP ASSEMBLY
RIGHT HEADLAMP
RIGHT REAR DOOR LATCH ASSEMBLY RIGHT REAR WINDOW SWITCH
RIGHT REAR DOOR MODULE (RRDM) RIGHT REAR WINDOW MOTOR
RIGHT REPEATER LAMP
S/P FAN RELAY
TRACTION CONTROL SWITCH
W/ HID RIGHT HEADLAMP
W/O HID
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> (IN PASSENGER DOOR HARN, 32 CM FROM FRONT PASSENGER WINDOW MOTOR CONNECTOR
