Cadillac STS I (2004-2007) front passenger door handle switch assembly Wiring diagram

740 5060 5967 5971 5878 5703 5702 451 COMPUTER DATA LINES SYSTEM BLK WIRE BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DOOR AJAR SWITCH DOOR OPEN SWITCH DOOR LATCH MOTOR FRONT PASSENGER DOOR HANDLE SWITCH ASSEMBLY FRONT PASSENGER DOOR LATCH ASSEMBLY FRONT PASSENGER DOOR LOCK SWITCH FRONT PASSENGER DOOR MODULE (FPDM) (IN DOOR) FRONT PASSENGER DOOR STATUS INDICATOR GMLAN SERIAL DATA GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL MODULE INTERIOR REAR COMPARTMENT RELEASE SWITCH LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT) LIFT SWITCH UNLATCH ENABLE SWITCH LOCK LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE ORG/BLK WIRE PNK 1 2 WIRE PNK WIRE PPL PPL/WHT WIRE REAR INTEGRATION MODULE (RIM) (UNDER LEFT SIDE OF REAR SHELF) RED/WHT WIRE RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT) RT FRT DOOR MODULE FUSE SPLICE PACK TAN/WHT WIRE TRUNK AJAR SIG TRUNK DIODE TRUNK DOOR RELEASE RELAY TRUNK DOOR/ VALET FUSE TRUNK LID RELEASE ACTUATOR TRUNK RELEASE CTRL UNLOCK VALET LOCKOUT SW VALET SWITCH WHT WIRE YEL WIRE
