Cadillac STS I (2004-2007) ecm/ tcm/ ipc fuse Wiring diagram
This page shows the only wiring diagram for the component.ecm/ tcm/ ipc fuse, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecm/ tcm/ ipc fuse (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 PPL
24 25 PPL
28 29 30 PPL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CANISTER VENT FUSE
DK GRN WIRE
DK GRN/WHT WIRE
ECM FUSE
ECM/ TCM/ IPC FUSE
ECM/TCM FUSE CAM FUSE FUSE
FUEL PUMP MOTOR RELAY
FUEL PUMP MTR FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
IGN 1 RELAY
IGNITION COIL 1 (REAR OF RIGHT CYL HEAD)
IGNITION COIL 2 (FRONT OF LEFT CYL HEAD)
IGNITION COIL 3 (CENTER OF RIGHT CYL HEAD)
IGNITION COIL 4 (CENTER OF LEFT CYL HEAD)
IGNITION COIL 5 (FRONT OF RIGHT CYL HEAD)
IGNITION COIL 6 (REAR OF LEFT CYL HEAD)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
MAF FUSE
MAIN RELAY
NCA WIRE
ODD COILS FUSE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL/WHT WIRE
PRE POST EVEN COILS FUSE
RED/WHT WIRE
RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT)
SPARK PLUG
SPLICE PACK
TAN WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT)
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.6l vin 7 (2 of 4) -> ECM/ TCM/ IPC FUSE
