Cadillac STS I (2004-2007) driver lumbar motor assembly Wiring diagrams
This page contains all the electrical diagrams for the component. driver lumbar motor assembly, in which he is found in the car Cadillac STS I (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver lumbar motor assembly wiring diagram (1 of 2)
BAT POS VOLTAGE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER LUMBAR MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT RECLINE MOTOR ASSEMBLY
GRY WIRE
HOT AT ALL TIMES
HUD FUSE
INSTRUMENT PANEL MODULE (IPM) (BEHIND GLOVE BOX)
LEFT REAR FUSE BLOCK (UNDER LEFT SIDE OF REAR SEAT)
LOW SPD GMLAN SERIAL DATA
LT BLU WIRE
MEMORY SEAT MODULE (UNDER DRIVER SEAT)
ORG/ WIRE
ORG/WHT WIRE
OUT
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER SEATS CIRCUIT BREAKER
RED/WHT WIRE
TAN WIRE
TELESCOPE IN TELESCOPE OUT
TELESCOPING ACTUATOR
TILT ACTUATOR
TILT UP
TILT/ TELESCOPE SWITCH TILT DOWN
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Memory power tilt & power telescopic circuit -> DRIVER LUMBAR MOTOR ASSEMBLY
driver lumbar motor assembly wiring diagram (2 of 2)
BRN/WHT WIRE
CLIMATE CONTROL SEAT MODULE (PASSENGER) (UNDER RIGHT FRONT SEAT)
DK BLU WIRE
DK GRN WIRE
DRIVER LUMBAR MOTOR ASSEMBLY
DRIVER LUMBAR POSITION SENSORS
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT FRONT VERTICAL MOTOR
DRIVER SEAT FRONT VERTICAL POSITION SENSOR
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT HORIZONTAL POSITION SENSOR
DRIVER SEAT REAR VERTICAL MOTOR
DRIVER SEAT REAR VERTICAL POSITION SENSOR
DRIVER SEAT RECLINE MOTOR ASSEMBLY
DRIVER SEAT RECLINE POSITION SENSOR
GRY WIRE
HORIZONTAL
LT BLU WIRE
LT GRN WIRE
MEMORY POWER TILT, POWER TELESCOPIC CIRCUIT
PNK WIRE
PWM SERIAL DATA PWM SERIAL DATA
TAN WIRE
VERTICAL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Memory seat circuit (2 of 2) -> DRIVER LUMBAR MOTOR ASSEMBLY
