Cadillac STS I (2004-2007) cellular navigation and digital radio antenna Wiring diagram
This page shows the only wiring diagram for the component.cellular navigation and digital radio antenna, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cellular navigation and digital radio antenna (1 of 1)
ANTENNA SIG
BARE AUX AUD SCRN LT TV AUD SIG RT TV AUD SIG LOW REF
BATTERY
BLK WIRE
CELLULAR NAVIGATION AND DIGITAL RADIO ANTENNA
COAX
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO RECEIVER (IN PASSENGER COMPT, ON LEFT SIDE OF REAR PACKAGE SHELF)
DK GRN WIRE
GROUND LOW REF
GRY/BLK WIRE
HOT AT ALL TIMES
LT BLU/WHT WIRE
LT GRN/WHT WIRE
RADIO
RED WIRE
RED/WHT WIRE
RF HTDST/ S-BAND FUSE
RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT)
SERIAL DATA
WHT WIRE
Go to component -> Satellite radio circuit -> CELLULAR NAVIGATION AND DIGITAL RADIO ANTENNA
