Cadillac STS I (2004-2007) 2 1 2501 2500 computer data lines system serial data serial data Wiring diagram

2 1 2501 2500 COMPUTER DATA LINES SYSTEM SERIAL DATA SERIAL DATA 3.6L 4.6L A/C COMP CLUTCH RELAY A/C COMPRESSOR CLUTCH A/C REFRIGERANT PRESSURE SENSOR (NEAR THE LEFT FRONT STRUT TOWER) BLK WIRE BLK/WHT WIRE COMP CLTCH FUSE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE (ECM) (FRONT OF ENGINE, ON RIGHT VALVE COVER) ENGINE CONTROLS SYSTEM FEED GRY WIRE HOT AT ALL TIMES HOT W/ IGN 1 RELAY ENERGIZED IGN 1 FUSE ORG/ WIRE ORG/BLK (OR RED/BLK) WIRE ORG/BLK WIRE PNK WIRE RED WIRE RED/BLK WIRE RIGHT REAR FUSE BLOCK (UNDER RIGHT SIDE OF REAR SEAT) RTN S107 (3.6L) (IN ENGINE HARN, 36 CM FROM BRAKE PRESSURE SENSOR CONNECTOR) SERIAL DATA SIG SPLICE PACK TAN (OR BLK/WHT) WIRE TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT) WHT WIRE
