Cadillac STS I (2004-2007) 170 ohms Wiring diagram
This page shows the only wiring diagram for the component.170 ohms, which is found in the car Cadillac STS I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 170 ohms (1 of 1)
170 OHMS
180 OHMS
3.6L
3.6L 4.6L
4.6L
AUTOMATIC TRANSMISSION
BATTERY
BLK WIRE
BLK/WHT WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
HI SPEED GMLAN SERIAL DATA -
HOT IN RUN OR START
IGN 1 RELAY
IGNITION MODE DATA SIGNAL
IGNITION MODE SWITCH
INSTRUMENT PANEL MODULE (IPM) (RIGHT SIDE OF DASH, BEHIND GLOVE BOX)
IPM HIGH SPEED GMLAN SERIAL DATA -
LT GRN WIRE
ON OFF
ORG/BLK WIRE
PARK/NEUTRAL SIGNAL
PNK WIRE
PPL
RED WIRE
STARTER
STARTER FUSE
STARTER RELAY
STARTER RELAY COIL CONTROL
STARTER RELAY FUSE
TAN WIRE
TAN/BLK WIRE
TRANSMISSION MANUAL SHIFT SHAFT SWITCH ASSEMBLY
UNDERHOOD FUSE BLOCK (RIGHT FRONT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
Go to component -> Starting circuit -> 170 OHMS
