Car Wiring Diagrams for Starting circuit for Cadillac SRX II facelift (2012-2016)

AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INTERNAL MODE SWITCH (IMS) BATTERY BATTERY CURRENT SENSOR (ON NEGATIVE BATTERY CABLE, NEAR BATTERY) BATTERY FUSE BLOCK (NEAR LEFT FRONT STRUT) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DK BLU/LT GRN WIRE ENGINE CONTROL MODULE (LEFT FRONT ENGINE COMPT) FUSE 42 FUSE 5 FUSE 6 GRY WIRE HIGH SPEED GMLAN SERIAL DATA (+) IGN MODE DATA SIGNAL IGNITION MODE SWITCH PARK/NEUTRAL SIG REAR ENGINE COMPT) RED WIRE RED/BLK WIRE START RLY COIL CTRL STARTER MOTOR STARTER RELAY TRANSMISSION CONTROL MODULE (TCM) UNDERHOOD FUSE BLOCK (LEFT FRONT ENGINE COMPT) VIO WIRE VIO/GRY WIRE WHT WIRE WHT/GRY WIRE
