Cadillac SRX II facelift (2012-2016) stop lamp rly coil sply volt Wiring diagrams
This page contains all the electrical diagrams for the component. stop lamp rly coil sply volt, in which he is found in the car Cadillac SRX II facelift (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
stop lamp rly coil sply volt wiring diagram (1 of 2)
1 2 3 GND
13 14 15 16 17 18 RUN/CRANK IGN 1 VOLT STOP LAMP RLY COIL SPLY VOLT
2 3 4 5 6 7 8 9 10 11 12 RIGHT TRAILER TURN SIG LAMP
23 24 DATA BUS - DATA BUS +
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
BRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/VIO WIRE
EXTERIOR LAMPS CIRCUIT
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
LEFT TRAILER PARK LAMP TRAILER BRAKE LAMP
LF TURN SIG LP SPLY VOLT
LOW SPEED GMLAN SERIAL DATA
LR STOP LAMP LP SPLY VOLT
LR TURN SIG LP SPLY VOLT
LT GRN WIRE
LT GRN/DK BLU WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
ORG/ WIRE
PNK/BLK WIRE
POWER RELAY
PPL/WHT WIRE
RBEC 1 FUSE
REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL)
RED/GRY WIRE
RED/LT GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RF TURN SIG LP SPLY VOLT
RIGHT TRAILER PARK LAMP LEFT TRAILER TURN SIG LAMP
RR STOP LAMP LP SPLY VOLT
RR TURN SIG LP SPLY VOLT
RUN RLY COIL CTRL
SIG GND
STOP LAMP RLY COIL SPLY VOLT
TRAILER BACKUP LAMP TRAILER FOG LAMP
TRAILER BRAKE LAMP
TRAILER CONNECTED SIG
TRAILER CONNECTOR
TRAILER IGNITION
TRAILER LIGHTING CONTROL MODULE (CARGO COMPT)
TRLR 2 FUSE
TRLR EXP FUSE
TRLR TRLR MDL MDL FUSE FUSE
UNDERHOOD FUSE BLOCK (LEFT FRONT ENGINE COMPT)
VIO/BLK WIRE
VIO/BRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component -> Trailer tow circuit, with heavy duty trailer provisions -> STOP LAMP RLY COIL SPLY VOLT
stop lamp rly coil sply volt wiring diagram (2 of 2)
1335 1335 7542 (BLUNT CUT TRAILER PROVISION)
2 23 24 SIG GND DATA BUS - DATA BUS +
22 8 17 PARK LAMP SPLY LEFT TRAILER RIGHT TRAILER
BATTERY FUSE FUSE BLOCK (NEAR LEFT FRONT STRUT)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/VIO WIRE
EXTERIOR LAMPS CIRCUIT
FUSE
GRY/BRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY TRLR LT S/T LMP FUSE
LF TURN SIG LP SPLY VOLT
LR STOP LAMP LP SPLY VOLT
LR TURN SIG LP SPLY VOLT
LT GRN/BRN WIRE
LT GRN/VIO WIRE
PRK LPS TRLR FUSE
RBEC
RED WIRE
RED/GRY WIRE
RF TURN SIG LP SPLY VOLT
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RR STOP LAMP LP SPLY VOLT
RR TURN SIG LP SPLY VOLT
STOP LAMP RLY COIL SPLY VOLT
TRAILER CONNECTOR
TRAILER PARK LAMPS RELAY
TRLR RT S/T LMP FUSE
VIO/WHT WIRE
WHT WIRE
WHT/YEL WIRE
YEL/DK BLU WIRE
YEL/GRY WIRE
Go to component -> Trailer tow circuit, without heavy duty trailer provisions -> STOP LAMP RLY COIL SPLY VOLT
