Cadillac SRX II facelift (2012-2016) right temperature up switch Wiring diagrams
This page contains all the electrical diagrams for the component. right temperature up switch, in which he is found in the car Cadillac SRX II facelift (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right temperature up switch wiring diagram (1 of 3)
A/C REFRIGERANT PRESSURE SENSOR (LEFT FRONT FRAME RAIL)
AUTO SWITCH
BLK WIRE
BLK/BRN WIRE
BLK/LT GRN WIRE
BLOWER DOWN SWITCH
BLOWER UP SWITCH
BRN/RED WIRE
BRN/YEL WIRE
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN LOW SPEED RESISTOR (FAN SHROUD)
COOLING FAN MEDIUM SPEED RELAY
COOLING FAN MEDIUM SPEED RESISTOR (FAN SHROUD)
COOLING FAN MOTOR
COOLING FAN RELAY
COOLING FAN SPEED CONTROL RELAY
DISPLAY
DK BLU WIRE
ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
ENGINE COOLANT TEMPERATURE SENSOR (REAR LEFT CYLINDER HEAD)
GRY WIRE
HIGH SPEED COOLING FAN DIODE
HOT AT ALL TIMES
INFO DISPLAY MODULE
LEFT TEMPERATURE DOWN SWITCH
LEFT TEMPERATURE UP SWITCH
LOGIC
LOW SPEED COOLING FAN DIODE
LT GRN WIRE
LT GRN/VIO WIRE
LT GRN/YEL WIRE
MEDIUM SPEED COOLING FAN DIODE
NCA WIRE
NETWORK
ORG/ WIRE
PPL/WHT WIRE
RADIO/HVAC CONTROLS
RECIRCULATION SWITCH
RIGHT AIR TEMPERATURE ACTUATOR (RIGHT CENTER OF HVAC CASE)
RIGHT TEMPERATURE DOWN SWITCH
RIGHT TEMPERATURE UP SWITCH
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (LEFT FRONT
WHT WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
WINDSHIELD DEFROST SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (3 of 4) -> RIGHT TEMPERATURE UP SWITCH
right temperature up switch wiring diagram (2 of 3)
