Cadillac SRX II facelift (2012-2016) right front vertical wheel acceleration sensor (right front wheel wiring diagram

ACCEL SENS SIG ACCEL SENS SIG RF ACCEL SENS SIG BAT POS VOLT RR DAMPER LOW REF RR DAMPER CTRL LR DAMPER CTRL LR DAMPER LOW REF BLK WIRE BLK/BRN WIRE BLK/GRY WIRE BLK/LT GRN WIRE BLK/PPL WIRE BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH) BRN WIRE BRN/LT GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/GRY WIRE DK BLU/YEL WIRE ELECTRONIC SUSPENSION CONTROL MODULE (CARGO COMPT) GRY WIRE GRY/RED WIRE GRY/WHT WIRE HOT W/ BATTERY SAVER RELAY 2 ENERGIZED SADS MDL FUSE LEFT FRONT SHOCK ABSORBER ACTUATOR (LEFT FRONT STRUT) LEFT FRONT VERTICAL BODY ACCELERATION SENSOR (LEFT FRONT STRUT) LEFT FRONT VERTICAL WHEEL ACCELERATION SENSOR (LEFT FRONT WHEEL SPEED SENSOR) LEFT REAR SHOCK ABSORBER ACTUATOR (LEFT REAR STRUT) LF DAMPER LOW REF LF DAMPER CTRL RF DAMPER LOW REF RF DAMPER CTRL LF WHEEL LOW REF RF WHEEL LOW REF LOW REF LOW REF LOW REF LF WHEEL REF VOLT RF WHEEL REF VOLT REF VOLT REF VOLT REF VOLT LF WHEEL SIG LT BLU WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE LT GRN/GRY WIRE LT GRN/VIO WIRE PNK/BLK WIRE REAR FUSE BLOCK (LEFT REAR QUARTER PANEL) REAR VERTICAL BODY ACCELERATION SENSOR (REAR UNDERCARRIAGE) RED/GRY WIRE RF WHEEL SIG RIGHT FRONT SHOCK ABSORBER ACTUATOR (RIGHT FRONT STRUT) RIGHT FRONT VERTICAL BODY ACCELERATION SENSOR (RIGHT FRONT STRUT) RIGHT FRONT VERTICAL WHEEL ACCELERATION SENSOR (RIGHT FRONT WHEEL RIGHT QUARTER PANEL RIGHT REAR SHOCK ABSORBER ACTUATOR (RIGHT REAR STRUT) SERIAL DATA SERIAL DATA - SERIAL DATA + SERIAL DATA + SERIAL DATA - SERIAL DATA BUS+ SERIAL DATA BUS+ SERIAL DATA BUS - SERIAL DATA BUS - SPEED SENSOR VIO/RED WIRE WHT WIRE WHT/BRN WIRE WHT/DK BLU WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE
