Cadillac SRX II facelift (2012-2016) park brake warning ind Wiring diagram
This page shows the only wiring diagram for the component.park brake warning ind, which is found in the car Cadillac SRX II facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park brake warning ind (1 of 1)
2500 2500 2500 COMPUTER DATA LINES
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/VIO WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL) PRK BRK MDL FUSE
INSTRUMENT CLUSTER
LOGIC
PARK BRAKE CONTROL SWITCH
PARK BRAKE WARNING IND
PARKING BRAKE CONTROL MODULE
PRK BRK SW APPLY SIG PRK BRK SW RELEASE SIG
RED WIRE
RED/VIO WIRE
SYSTEM
VIO WIRE
WHT WIRE
WHT/DK BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Park brake system circuit -> PARK BRAKE WARNING IND
