Cadillac SRX II facelift (2012-2016) lh seat mode sig Wiring diagram
This page shows the only wiring diagram for the component.lh seat mode sig, which is found in the car Cadillac SRX II facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh seat mode sig (1 of 1)
BLK WIRE
BRN WIRE
BRN/DK BLU WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DK GRN/VIO WIRE
DRIVER BACK SEAT BLOWER MOTOR (IF EQUIPPED)
DRIVER BACK SEAT HEATING ELEMENT
DRIVER COOLED SEAT SWITCH
DRIVER CUSHION SEAT HEATING ELEMENT
DRIVER HEATED SEAT SWITCH
DRV SEAT MTR CTRL PASS SEAT HTR CTRL
FRONT SEAT HEATING CONTROL MODULE
FRT VENT SEAT FUSE
GND RH SEAT MODE SIG IGN
GRY WIRE
HIGH HEAT IND
HIGH HEAT MED HEAT
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
HTR DR CIRCUIT BREAKER
HTR PAS CIRCUIT BREAKER
IGN
IGN LH SEAT MODE SIG
IGN RH SEAT MODE SIG GND
IND IND
INFO DISPLAY MODULE
INSTRUMENT PANEL FUSE BLOCK (CENTER CONSOLE)
LH SEAT MODE SIG
LOGIC
LOW HEAT IND
LT GRN WIRE
LT GRN/DK BLU WIRE
LT GRN/VIO WIRE
MED HEAT IND
MID SPD GMLAN
NCA WIRE
NETWORK BUS 2
PASSENGER BACK SEAT BLOWER MOTOR (IF EQUIPPED)
PASSENGER BACK SEAT HEATING ELEMENT
PASSENGER COOLED SEAT SWITCH
PASSENGER CUSHION SEAT BLOWER MOTOR (IF EQUIPPED)
PASSENGER CUSHION SEAT HEATING ELEMENT
PASSENGER HEATED SEAT SWITCH
RADIO/HVAC CONTROLS
REAR FUSE BLOCK (LEFT REAR QUARTER PANEL)
RED WIRE
RED/YEL WIRE
VIO WIRE
VIO/BLK WIRE
YEL WIRE
Go to component -> Front heated seats circuit -> LH SEAT MODE SIG
