Cadillac SRX II facelift (2012-2016) ecm pwr/trn fuse Wiring diagram
This page shows the only wiring diagram for the component.ecm pwr/trn fuse, which is found in the car Cadillac SRX II facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecm pwr/trn fuse (1 of 1)
AIR QUALITY SENSOR (W/ AUTOMATIC AIR RECIRCULATION SENSOR INDICATOR)
DK BLU VIO/ WIRE
ECM PWR/TRN FUSE
ENGINE CONTROL MODULE
ENGINE CONTROLS IGNITION RELAY
FROM COOL FAN 1 FUSE (DIAGRAM 2 OF 8)
FROM TCM RUN CRNK FUSE (DIAGRAM 2 OF 8)
FSCM FUSE
FUEL COMPOSITION SENSOR
FUEL PUMP DRIVER CONTROL MODULE
FUSE
HEATED OXYGEN ENGINE SENSOR CONTROL BANK 1 MODULE SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 2
HVAC AUXILIARY CONTROL HVAC MODULE CONTROL MODULE
IGNITION COIL 5
IGNITION COIL 6
IGNITION IGNITION COIL 3 COIL 1
IGNITION IGNITION COIL 4 COIL 2
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INJ EVEN FUSE
INJ ODD FUSE
MULTI-FUNCTION INTAKE AIR SENSOR
NCA WIRE
PASSENGER AIR BAG DISABLE INDICATOR
PNK WIRE
PPL/GRY WIRE
PPL/WHT WIRE
REC RUN CRNK FUSE
SDM IGN FUSE
SENS AIR QUAL FUSE
TO REAR FUSE BLOCK (DIAGRAM 6 OF 8)
VIO/BLK WIRE
VIO/DK BLU WIRE
VIO/GRY WIRE
VIO/LT GRN WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 8) -> ECM PWR/TRN FUSE
