Cadillac SRX II facelift (2012-2016) b+ voltage warning ind ctrl Wiring diagram
This page shows the only wiring diagram for the component.b+ voltage warning ind ctrl, which is found in the car Cadillac SRX II facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram b+ voltage warning ind ctrl (1 of 1)
1 2 3 4 5 6 7 8 9 10 GROUND
B+ VOLTAGE WARNING IND CTRL
BLK WIRE
CENTER CONSOLE MULTI-FUNCTION SWITCH
COLLISION ALERT INDICATORS (CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DIMM CONTROL
FRONTVIEW CAMERA MODULE
GROUND
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
IGN VOLTAGE
INSTRUMENT CLUSTER
LANE DEP WARNING DIS SW
LANE DEPARTURE WARNING DIS SWITCH
LANE DEPARTURE WARNING IND
LED CONTROL
LOGIC
LOW SPD GMLAN SER DATA
LT GRN WIRE
MOST SER DATA (+) MOST SER DATA (-)
RADIO
REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL)
RED WIRE
RED/LT GRN WIRE
RPA MDL FUSE
SER DATA
VIO/GRY WIRE
WHT WIRE
WHT/GRN WIRE
WHT/LT GRN WIRE
Go to component -> Lane departure warning circuit -> B+ VOLTAGE WARNING IND CTRL
