Cadillac SRX II facelift (2012-2016) audio/ video input transmission adapter shift lever Wiring diagram
This page shows the only wiring diagram for the component.audio/ video input transmission adapter shift lever, which is found in the car Cadillac SRX II facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram audio/ video input transmission adapter shift lever (1 of 1)
AUDIO/ VIDEO INPUT TRANSMISSION ADAPTER SHIFT LEVER
AUXILIARY AUDIO INPUT
BATTERY
BATTERY CURRENT SENSOR
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CENTER CONSOLE ACCESSORY POWER RECEPTACLE 1
CENTER CONSOLE COMPARTMENT ACCESSORY POWER RECEPTACLE
CENTER CONSOLE MULTI-FUNCTION SWITCH
DRIVER SEATBACK VIDEO DISPLAY
ELECTRONIC BREAK CONTROL MODULE
HEADLAMP WASHER PUMP
HOOD AJAR SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
INSTRUMENT PANEL MULTI-FUNCTION SWITCH 1
PARK BRAKE CONTROL SWITCH
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP
RIGHT LEFT LOWER INSTRUMENT INSTRUMENT PANEL PANEL COURTESY ACCENT LAMP LAMP
RIGHT LOWER INSTRUMENT PANEL ACCENT LAMP
W/ AMPLIFIER W/O AMPLIFIER PASSENGER SEATBACK VIDEO DISPLAY RADIO
W/ DUAL DISPLAY
W/ HIGH PRESSURE HEADLAMP WASHER
W/ LEATHER TRIM SEAT
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WIPER HIGH SPEED DIODE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
Go to component -> Ground distribution circuit (1 of 5) -> AUDIO/ VIDEO INPUT TRANSMISSION ADAPTER SHIFT LEVER
