Cadillac SRX II facelift (2012-2016) 1 2 3 4 5 6 low spd gmlan Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 low spd gmlan, which is found in the car Cadillac SRX II facelift (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 low spd gmlan (1 of 1)
1 2 3 4 5 6 7 8 ACT FORWARD CTRL REARWARD CTRL
1 2 3 4 5 6 LOW SPD GMLAN
ADJUSTABLE PEDAL CIRCUIT
BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU/VIO WIRE
DK BLU/YEL WIRE
DOWN
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR (UNDER DRIVER'S SEAT)
DRIVER SEAT HORIZONTAL MOTOR
DRIVER SEAT REAR VERTICAL MOTOR (UNDER DRIVER'S SEAT)
FORWARD RECLINE
GROUND
GRY/BLK WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/LT GRN WIRE
HORIZONTAL
HORIZONTAL FORWARD
LT GRN WIRE
LT GRN/BRN WIRE
LT GRN/GRY WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
MEMORY SEAT MODULE (MSM) (UNDER DRIVER'S SEAT)
MID SPEED GMLAN
MOTOR FORWARD CTRL MOTOR REARWARD CTRL
REAR
REARWARD
REARWARD RECLINE
VERTICAL
VERTICAL DOWN
VERTICAL MOTOR UP
VERTICAL UP SWITCH
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/LT BLU WIRE
Go to component -> Memory seat circuit (2 of 2) -> 1 2 3 4 5 6 LOW SPD GMLAN
