Car Wiring Diagrams for Park brake system circuit for Cadillac SRX II (2009-2012)

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE HOT AT ALL TIMES PRK BRK MDL FUSE LT BLU WIRE PARK BRAKE CONTROL SWITCH PARKING BRAKE CONTROL MODULE PPL REAR BODY FUSE BLOCK RED WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE WHT WIRE YEL WIRE
