Cadillac SRX II (2009-2012) w/ w/ am/fm wireless stereo interface radio Wiring diagram
This page shows the only wiring diagram for the component.w/ w/ am/fm wireless stereo interface radio, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ w/ am/fm wireless stereo interface radio (1 of 1)
2.8L
BATTERY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
CENTER CONSOLE COMPARTMENT ACCESSORY POWER TRANSMISSION RECEPTACLE SHIFT LEVER
CENTER CONSOLE MULTI-FUNCTION SWITCH
DRIVER SEAT HEADREST VIDEO DISPLAY
ELECTRONIC BREAK CONTROL MODULE
HEADLAMP WASHER FLUID PUMP
INSTRUMENT PANEL BLOWER ACCESSORY MOTOR POWER CONTROL RECEPTACLE MODULE
LEFT RIGHT INSTRUMENT INSTRUMENT PANEL PANEL ACCENT ACCENT LAMP LAMP
MULTIMEDIA MOBILE PLAYER TELEPHONE INTERFACE CONTROL MODULE MODULE RADIO
NCA WIRE
PARK TRANSMISSION BRAKE SHIFT LEVER CONTROL POSITION SWITCH INDICATOR
PASSENGER SEAT HEADREST VIDEO DISPLAY
REAR AUDIO CONTROL MODULE
REAR ENGINE COMPT)
RIGHT FRONT SIDE MARKER LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT LOWER INSTRUMENT INSTRUMENT PANEL PANEL ACCENT COMPARTMENT LAMP LAMP
RIGHT PARK/ TURN SIGNAL LAMP
W/ AUDIO CONTROL REAR SEAT, EARPHONE JACKS, DISPLAY
W/ DELUXE PACKAGE INTERIOR LAMP
W/ ENTERTAINMENT PACKAGE
W/ HID W/O HID
W/ HIGH PRESSURE HEADLAMP WASHER
W/ LEATHER TRIM SEAT
W/ W/ AM/FM WIRELESS STEREO INTERFACE RADIO
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WIPER HIGH SPEED DIODE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
Go to component -> Ground distribution circuit (1 of 4) -> W/ W/ AM/FM WIRELESS STEREO INTERFACE RADIO
