Cadillac SRX II (2009-2012) trlr lt s/t lmp fuse Wiring diagram
This page shows the only wiring diagram for the component.trlr lt s/t lmp fuse, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trlr lt s/t lmp fuse (1 of 1)
22 8 17 PARK LAMP SPLY LEFT TRAILER RIGHT TRAILER
23 24 DATA BUS - DATA BUS +
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRL CTRL
EXTERIOR LAMPS CIRCUIT
HOT AT ALL TIMES
LEFT TRAILER STOP/ TURN SIGNAL LAMP RELAY
LT BLU/WHT WIRE
ORG/ WIRE
PRK LPS TRLR FUSE
REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL)
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RR TURN SIG LP SPLY VOLT
TAN WIRE
TAN/BLK WIRE
TRAILER CONNECTOR
TRAILER PARK LAMP RELAY
TRLR LT S/T LMP FUSE
TRLR RT S/T LMP FUSE
YEL WIRE
YEL/BLK WIRE
Go to component -> Trailer tow circuit, without heavy duty trailer provisions -> TRLR LT S/T LMP FUSE
