Cadillac SRX II (2009-2012) trailer ignition Wiring diagram
This page shows the only wiring diagram for the component.trailer ignition, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer ignition (1 of 1)
BLK WIRE
DK BLU WIRE
DRIVER SEAT HEADREST VIDEO DISPLAY
ELECTRONIC SUSPENSION CONTROL MODULE
FROM LGM LOGIC FUSE (DIAGRAM 7 OF 8)
FROM LOGISTIC MODE RELAY 1 (DIAGRAM 6 OF 8)
GARAGE DOOR OPENER (IF EQUIPPED)
L/GATE FUSE
LIFTGATE RELEASE RELAY
LOGISTIC MODE RELAY 2
LT GRN WIRE
NEAR BRANCH TO INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE)
PARKING ASSIST CONTROL MODULE
PASSENGER SEAT HEADREST VIDEO DISPLAY
RDM FUSE INFOTMNT FUSE
REAR DEFOGGER RELAY
REAR DIFFERENTIAL CLUTCH CONTROL MODULE (W/ ALL WHEEL DRIVE)
REAR WIPER
REAR WIPER MOTOR
RED WIRE
RELAY
RPA MDL FUSE
SADS MDL FUSE
SEC FUSE
SECURITY SIREN
TRAILER IGNITION
TRAILER PARK LAMP RELAY
UGDO FUSE
ULTRASONIC INTRUSION SENSOR
W/ REAR SEAT ENTERTAINMENT
W/ VARIABLE REAL TIME DAMPING
WHT WIRE
WPR REAR FUSE
Go to component -> Power distribution circuit (8 of 8) -> TRAILER IGNITION
