Cadillac SRX II (2009-2012) serial data wakeup signal Wiring diagram

2.8L 3.0L 3.0L 2.8L BRN WIRE CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE DK GRN WIRE DRIVER WINDOW MOTOR (IN DRIVER'S DOOR) DRIVER WINDOW SWITCH ENGINE CONTROL MODULE (LEFT FRONT ENGINE COMPT) FRONT PASSENGER WINDOW MOTOR (IN FRONT PASSENGER DOOR) GRY WIRE HIGH SPEED GMLAN SERIAL DATA (+) LEFT REAR WINDOW SWITCH LIFTGATE CONTROL MODULE LOCAL INTERCONNECT NETWORK 3 LOCAL INTERCONNECT NETWORK 4 LOW SPEED GMLAN SERIAL DATA LT BLU WIRE NCA WIRE NETWORK 4 LOCAL INTERCONNECT PARKING BRAKE CONTROL MODULE PASSENGER PRESENCE DETECTION MODULE (IF EQUIPPED) RAIN SENSOR REAR SEAT HEATING CONTROL MODULE RIGHT REAR WINDOW SWITCH SERIAL DATA COMMUNICATION ENABLE SERIAL DATA WAKEUP SIGNAL SUNROOF SUNROOF SUNSHADE CONTROL MOTOR MODULE MODULE TAN WIRE TAN/BLK WIRE TRAILER BRAKE CONTROL MODULE TRANSMISSION CONTROL MODULE TRANSMISSION MANUAL SHIFT SWITCH W/ SUNROOF W/O AWD W/O SUNROOF
