Cadillac SRX II (2009-2012) rdo uhp disply fuse fuse fuse Wiring diagram
This page shows the only wiring diagram for the component.rdo uhp disply fuse fuse fuse, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rdo uhp disply fuse fuse fuse (1 of 1)
AUX PWR FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
CARGO ACCESSORY POWER RECEPTACLE
DK BLU WIRE
DRIVER WINDOW MOTOR
FROM RBEC 1 FUSE (DIAGRAM 1 OF 8)
FROM RBEC 2 FUSE (DIAGRAM 1 OF 8)
INFO DISPLAY MODULE
LEFT REAR WINDOW SWITCH
LIFTGATE PASSENGER CONTROL WINDOW MODULE MOTOR (LIFTGATE BODY EQUIPMENT)
LOGISTIC MODE RELAY 1
LT GRN WIRE
LT WDO FUSE
MOBILE TELEPHONE CONTROL MODULE (IF EQUIPPED)
MULTIMEDIA PLAYER INTERFACE MODULE
PRK BRK MDL FUSE
RADIO
RADIO/ HVAC CONTROL
RDO UHP DISPLY FUSE FUSE FUSE
REAR SEAT HEATING CONTROL MODULE (IF EQUIPPED)
RED WIRE
RIGHT REAR WINDOW SWITCH
RR HTD SEAT FUSE
RT WDO FUSE LGATE MDL FUSE
TO DRV PWR SEAT CIRCUIT BREAKER (DIAGRAM 7 OF 8)
TO LOGISTIC MODE RELAY 2 (DIAGRAM 8 OF 8)
TRAILER CONNECTOR (HEAVY DUTY TRAILER PROVISIONS) PARKING BRAKE CONTROL MODULE
TRLR 2 FUSE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit (6 of 8) -> RDO UHP DISPLY FUSE FUSE FUSE
