Cadillac SRX II (2009-2012) ppl aux video hi sig Wiring diagram
This page shows the only wiring diagram for the component.ppl aux video hi sig, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl aux video hi sig (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 BATT POS VOLT REMOTE ENABLE
1 2 3 4 5 6 7 VIDEO DRAIN WIRE
15 16 VIDEO MODE 2 SIG VIDEO BRIGHT SIG
AUDIO/VIDEO INPUT ADAPTER
AUX AUDIO LT SIG AUX AUDIO LT SIG DRAIN WIRE
BLK/WHT WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
GROUND
GROUND DVD VIDEO SIG 2 (+) DVD VIDEO SIG 2 (-)
LT GRN WIRE
NCA WIRE
ORG/BLK WIRE
PASSENGER SEAT HEADREST VIDEO DISPLAY
PNK/BLK WIRE
PPL
PPL AUX VIDEO HI SIG
PPL/WHT WIRE
RADIO CIRCUIT
REAR AUDIO CONTROL MODULE (IF EQUIPPED)
RED/WHT WIRE
REMOTE SIG (+) RH AUDIO SIG
TAN/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Video system circuit (2 of 2) -> PPL AUX VIDEO HI SIG
