Cadillac SRX II (2009-2012) pnk run/crank ign 1 volt Wiring diagram
This page shows the only wiring diagram for the component.pnk run/crank ign 1 volt, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk run/crank ign 1 volt (1 of 1)
BACKUP LAMP SPLY VOLT
BLK/WHT WIRE
CAMERA DRAIN WIRE
CAMERA FUSE
CAMERA SIG 2
CAMERA SIG 2 + PNK WIRE
HOT W/ IGNITION RUN RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK CAMERA SIG + CAMERA SIG 2 WIRE
PNK PNK WIRE
PNK RUN/CRANK IGN 1 VOLT WIRE
PNK WIRE
RADIO (BLUNT CUT SHIELD)
REAR FUSE BLOCK (LEFT REAR QUARTER PANEL)
REARVIEW CAMERA
SIG GND
W/ PARKING ASSIST SENSOR INDICATOR
Go to component -> Rear view camera circuit -> PNK RUN/CRANK IGN 1 VOLT WIRE
