Cadillac SRX II (2009-2012) pnk/ (engine harness, near the branch for the brake booster Wiring diagram
This page shows the only wiring diagram for the component.pnk/ (engine harness, near the branch for the brake booster, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk/ (engine harness, near the branch for the brake booster (1 of 1)
2.8L
3.0L
BLK WIRE
BRAKE BOOSTER PUMP MOTOR RELAY
COOLING FAN 1 FUSE
COOLING FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY (3.0L)
COOLING FAN LOW SPEED RELAY (3.0L)
COOLING FAN MEDIUM
COOLING FAN SPEED CONTROL 2 RELAY (3.0L)
COOLING FAN SPEED CONTROL RELAY (3.0L)
DIESEL FUEL/SEC AIR FUSE (2.8L)
ENGINE CONTROL MODULE (3.0L)
ENGINE IGNITION IGNITION CONTROL COIL 5 COIL 3 MODULE (3.0L)
EVAPORATIVE EMISSION PURGE SOLENOID VALVE
FROM ECM PWR/TRN FUSE (DIAGRAM 1 OF 8)
FROM POWERTRAIN RELAY (DIAGRAM 1 OF 8)
FUEL FUEL INJECTOR INJECTOR
FUEL IGNITION IGNITION INJECTOR COIL 4 COIL 2
FUEL INJECTOR
HEATED HEATED OXYGEN OXYGEN SENSOR SENSOR BANK 2 BANK 1 SENSOR 1 SENSOR 1
IGNITION COIL 1
IGNITION COIL 6
INJ EVEN FUSE
INJ ODD FUSE
MASS AIR FLOW/INTAKE AIR TEMPERATURE SENSOR
NCA WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/ (ENGINE HARNESS, NEAR BRANCH FOR BRAKE BOOSTER PUMP RELAY) WIRE
PNK/ (ENGINE HARNESS, NEAR THE BRANCH FOR THE BRAKE BOOSTER WIRE
PNK/ (ENGINE HARNESS, NEAR THE BRANCH FOR THE UNDERHOOD FUSE BLOCK) WIRE
PNK/ 2.8L WIRE
PRE FUSE
PUMP RELAY
REAR WINDOW WASHER PUMP RELAY
SECONDARY AIR INJECTION PUMP RELAY
SPEED 1 RELAY (3.0L)
TURBO CHARGER BYPASS SOLENOID VALVE
UNDERHOOD FUSE BLOCK (LEFT FRONT ENGINE COMPT)
WASHER FUSE
WHT WIRE
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER SPEED CONTROL RELAY
WIPER FUSE
Go to component -> Power distribution circuit (2 of 8) -> PNK/ (ENGINE HARNESS, NEAR THE BRANCH FOR THE BRAKE BOOSTER WIRE
