Cadillac SRX II (2009-2012) passenger outside rearview mirror glass Wiring diagram
This page shows the only wiring diagram for the component.passenger outside rearview mirror glass, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger outside rearview mirror glass (1 of 1)
BLK WIRE
DEFOGGER DISPLAY SWITCH
DK BLU WIRE
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
HOT AT ALL TIMES
HTD MIRR FUSE
HVAC CONTROL MODULE (CENTER OF DASH, UNDER RADIO)
LOGIC RADIO/HVAC CONTROLS
NETWORK 9
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR (RIGHT KICK PANEL)
PASSENGER OUTSIDE REARVIEW MIRROR GLASS
PPL
RBEC 1 FUSE BLOCK FUSE (LEFT FRONT ENGINE COMPT)
REAR DEFG FUSE
REAR DEFOG RLY CTRL
REAR DEFOGGER GRID
REAR DEFOGGER RELAY
REAR FUSE BLOCK (LEFT REAR QUARTER PANEL)
RED/BLK WIRE
UNDERHOOD
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit -> PASSENGER OUTSIDE REARVIEW MIRROR GLASS
