Cadillac SRX II (2009-2012) passenger door accent lamp (w/ deluxe package Wiring diagram
This page shows the only wiring diagram for the component.passenger door accent lamp (w/ deluxe package, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger door accent lamp (w/ deluxe package (1 of 1)
ACCENT LAMP (W/ LEATHER TRIM SEAT)
BATT POS VOLT
BCM 7 FUSE
BLK WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
COURTESY LP CTRL
DOME LAMP SWITCH
DRIVER DOOR ACCENT LAMP (W/ DELUXE PACKAGE INTERIOR LAMP)
DRIVER SEAT ACCENT LAMP (W/ LEATHER TRIM SEAT)
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RUN RELAY ENERGIZED
INADVERTENT PWR CTRL
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LAMP
INTR LP CTRL
LEFT CARGO LAMP
LEFT INSTRUMENT PANEL ACCENT LAMP (W/ DELUXE PACKAGE INTERIOR LAMP)
LEFT LOWER INSTRUMENT PANEL ACCENT LAMP (W/ LEATHER TRIM SEAT)
LEFT REAR DOOR ACCENT LAMP
LIFT GATE AJAR SW SIG
LIFTGATE COURTESY LAMP
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE ACCENT LAMP
PASSENGER DOOR ACCENT LAMP (W/ DELUXE PACKAGE
PASSENGER SEAT
PNK AMBIENT LIGHTING WIRE
PNK PNK 7557 7557 ACCENT LP CTRL WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL INTR LP DEFEAT SW SIG COURTESY LP SW SIG
REAR COMPT LP CTRL
RED/WHT WIRE
RIGHT CARGO LAMP
RIGHT INSTRUMENT PANEL ACCENT LAMP (W/ DELUXE PACKAGE INTERIOR LAMP)
RIGHT LOWER INSTRUMENT PANEL ACCENT LAMP (W/ DELUXE PACKAGE INTERIOR LAMP)
RIGHT LOWER INSTRUMENT PANEL ACCENT LAMP (W/ LEATHER TRIM SEAT)
RIGHT QUARTER PANEL
RIGHT REAR DOOR ACCENT LAMP
SDM IGN FUSE 54
SERIAL DATA
UNDERHOOD FUSE BLOCK (LEFT FRONT ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> PASSENGER DOOR ACCENT LAMP (W/ DELUXE PACKAGE
