Cadillac SRX II (2009-2012) pass dr pwr seat circuit breaker Wiring diagrams
This page contains all the electrical diagrams for the component. pass dr pwr seat circuit breaker, in which he is found in the car Cadillac SRX II (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pass dr pwr seat circuit breaker (1 of 3)
BATTERY
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DN FWD
FRONT VERTICAL DOWN
FRONT VERTICAL UP
HORIZ- ONTAL FWD
HORIZ- REAR VERTICAL UP ONTAL RWD
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PASS DR PWR SEAT CIRCUIT BREAKER
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT FRONT VERTICAL MOTOR (UNDER FRONT PASSENGER SEAT)
PASSENGER SEAT RECLINE MOTOR (UNDER FRONT PASSENGER SEAT)
REAR FUSE BLOCK (LEFT REAR QUARTER PANEL)
REAR VERTICAL DOWN
RECLINE FWD
RECLINE RWD
RED WIRE
RWD
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Passenger power seat circuit -> PASS DR PWR SEAT CIRCUIT BREAKER
Wiring diagram pass dr pwr seat circuit breaker (2 of 3)
Go to component -> Passenger"s lumbar circuit -> PASS DR PWR SEAT CIRCUIT BREAKER
Wiring diagram pass dr pwr seat circuit breaker (3 of 3)
AOS MDL FUSE
BLK WIRE
CNSTR VENT FUSE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
DRIVER WINDOW SWITCH
DRV PWR SEAT CIRCUIT BREAKER
EVAPORATIVE EMISSION VENT SOLENOID VALVE
FROM RR HTD SEAT FUSE (DIAGRAM 6 OF 8)
FRT HTD SEAT FUSE
FUEL PUMP CONTROL MODULE
FUEL PUMP FUSE
HEATED SEAT CONTROL MODULE
IGN/THEFT 1 FUSE
IGN/THEFT 2 FUSE
KEYLESS ENTRY CONTROL MODULE
LEFT MIRROR CONTROL MODULE (W/ MEMORY)
LGM LOGIC FUSE
LIFT GATE CONTROL MODULE (LIFTGATE BODY EQUIPMENT)
MDLTRLR FUSE
MIR WDO MDL FUSE
NCA WIRE
OUT SIDE REARVIEW MIRROR SWITCH (W/O MEMORY)
PASS DR PWR SEAT CIRCUIT BREAKER
PASS DR WDO SW FUSE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SUPPORT SWITCH
PASSENGER WINDOW SWITCH (W/ MEMORY)
RED WIRE
SEAT MEMORY CONTROL MODULE
TO LOGISTIC MODE RELAY 2 (DIAGRAM 8 OF 8)
TRAILER LIGHTING CONTROL MODULE (HEAVY DUTY TRAILER PROVISIONS)
W/ MEMORY
W/ MULTI- DIRECTIONAL PASSENGER ADJUSTER POWER SEAT
W/ POWER LUMBAR W/O POWER LUMBAR CONTROL SEAT CONTROL SEAT
W/O MEMORY
WHT WIRE
Go to component -> Power distribution circuit (7 of 8) -> PASS DR PWR SEAT CIRCUIT BREAKER
