Cadillac SRX II (2009-2012) local inter network 4 Wiring diagram
This page shows the only wiring diagram for the component.local inter network 4, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram local inter network 4 (1 of 1)
AUTO
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
BRN WIRE
CENTER CONSOLE MULTI-FUNCTION SWITCH MODULE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL, SOUND SYSTEMS
DK GRN WIRE
DOME LAMP SWITCH
GARAGE DOOR OPENER
GRY WIRE
HDLP SW PRK LP SIG LED BACKLIGHT DIMMING CTRL
HDLP SW REF VOLT
HDLP SW SIG
HEAD
HEADLAMP SWITCH
HOT AT ALL TIMES BCM 6 FUSE
IGNITION MODE SWITCH
INSTRUMENT PANEL FUSE BLOCK (CENTER CONSOLE)
INTERIOR LIFTGATE CONTROL SWITCH
LED BACKLIGHT DIMMING CTRL
LED DIMMING SIG
LEFT STEERING WHEEL CONTROL
LOCAL INTER NETWORK 4
LOGIC
LT BLU WIRE
OFF
OUTSIDE REARVIEW MIRROR SWITCH
PARK
PARK BRAKE CONTROL SWITCH
PARKING ASSIST CONTROL MODULE (IF EQUIPPED)
PASSENGER WINDOW SWITCH
PPL/WHT WIRE
REAR PARK ASSIST LED DISABLE SIG
RED/WHT WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RIGHT REAR QUARTERPANEL)
RIGHT STEERING WHEEL CONTROL
SERIAL DATA GMLAN LOW SPEED
STEERING WHEEL AIR BAG COIL
SUNROOF SUNSHADE SWITCH (W/ ELECTRIC SLIDING SUNROOF)
SUNROOF SWITCH (W/ ELECTRIC SLIDING SUNROOF)
SWC BKLT FUSE 30
SWITCH
TRANSMISSION SHIFT LEVER POSITION INDICATOR
UNDERHOOD FUSE BLOCK (LEFT FRONT ENGINE COMPT)
W/ PARKING ASSIST
W/ POWER LIFTGATE, MEMORY
W/ POWER LIFTGATE, W/O MEMORY
W/O POWER LIFTGATE
YEL WIRE
Go to component -> Instrument illumination circuit -> LOCAL INTER NETWORK 4
