Cadillac SRX II (2009-2012) lf aud sig + rf aud sig + lr aud sig + rr aud sig + amplifier ctrl Wiring diagram
This page shows the only wiring diagram for the component.lf aud sig + rf aud sig + lr aud sig + rr aud sig + amplifier ctrl, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf aud sig + rf aud sig + lr aud sig + rr aud sig + amplifier ctrl (1 of 1)
8 7 6 5 4 3 2 1 GROUND
AMP RDO FUSE
AUDIO AMPLIFIER
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CENTER SPEAKER
INSTRUMENT PANEL FUSE BLOCK (CENTER CONSOLE)
LEFT FRONT SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT REAR CARGO DOOR SPEAKER (W/ SURROUND AMPLIFIER)
LEFT REAR SPEAKER
LEFT SPK OUT +
LF AUD SIG + RF AUD SIG + LR AUD SIG + RR AUD SIG + AMPLIFIER CTRL
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
RDO FUSE
RED/WHT WIRE
RIGHT FRONT SPEAKER
RIGHT FRONT TWEETER SPEAKER
RIGHT REAR CARGO DOOR SPEAKER (W/ SURROUND AMPLIFIER)
RIGHT REAR SPEAKER
SUBWOOFER SPEAKER
TAN WIRE
W/ SURROUND AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Radio circuit (5 of 5) -> LF AUD SIG + RF AUD SIG + LR AUD SIG + RR AUD SIG + AMPLIFIER CTRL
