Cadillac SRX II (2009-2012) left backup lamp left tail lamp Wiring diagram
This page shows the only wiring diagram for the component.left backup lamp left tail lamp, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left backup lamp left tail lamp (1 of 1)
23 24 1 DATA BUS - DATA BUS + B+
42 55 DATA BUS + DATA BUS -
5 8 6 PARK/NEU SIG DATA BUS + DATA BUS -
AUTOMATIC TRANSMISSION ASSEMBLY
BACKUP LP SPLY VOLT
BCM 1 FUSE
BLK WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL TRANSMISSION SOLENOID CONTROL VALVE MODULE ASSEMBLY (TCM)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
INSTRUMENT PANEL FUSE BLOCK (CENTER CONSOLE)
LEFT BACKUP LAMP LEFT TAIL LAMP
LOGIC
LOW REF
LT GRN WIRE
ORG/BLK WIRE
PARK/ NEUTRAL SW SIG
PARK/NEUTRAL SIG
RED WIRE
RED/WHT WIRE
RIGHT BACKUP LAMP RIGHT TAIL LAMP
RIGHT BACKUP LAMP RIGHT TAIL LAMP (W/ REAR FOG LAMP)
TAN WIRE
TAN/BLK WIRE
TRANS RANGE SIG A
TRANS RANGE SIG B
TRANS RANGE SIG C
TRANS RANGE SIG P
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> LEFT BACKUP LAMP LEFT TAIL LAMP
