Cadillac SRX II (2009-2012) hot w/ ignition run relay energized tcm/ run/ crnk fuse Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 B(+) 1-2/3-4 SHIFT SOLENOID VALVE AUTOMATIC TRANSMISSION ASSEMBLY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DATA BUS - DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) ENGINE CONTROL MODULE (ECM) (LEFT FRONT ENGINE COMPT) GEAR SHIFT POSITION SENSOR GMLAN GMLAN SERIAL DATA BUS + HOT AT ALL TIMES HOT W/ IGNITION RUN RELAY ENERGIZED TCM/ RUN/ CRNK FUSE INSTRUMENT CLUSTER LINE PRESSURE CONTROL SOLENOID VALVE LOGIC LOGIC DISPLAY NCA WIRE ORG/BLK WIRE P/N SIG PARK/NEUTRAL SIG DATA BUS (-) DATA BUS (+) DATA BUS (+) GND PNK IGN VOL WAKE-UP SIG WIRE PNK WIRE PPL PRESSURE CONTROL SOLENOID VALVE 1 PRESSURE CONTROL SOLENOID VALVE 3 PRESSURE CONTROL SOLENOID VALVE 4 RED/WHT WIRE TAN WIRE TAN/BLK WIRE TAP UP/TAP DOWN SW SIG PPL TCM BATT FUSE TORQUE CONVERTER CLUTCH PRESSURE CONTROL SOLENOID VALVE TRANS ENABLE SWITCH TRANSMISSION CONTROL MODULE TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR TRANSMISSION INPUT SHAFT SPEED SENSOR TRANSMISSION MANUAL SHIFT SWITCH TRANSMISSION OUTPUT SHAFT SPEED SENSOR TRANSMISSION SHIFT LEVER UNDERHOOD FUSE BLOCK (LEFT FRONT ENGINE COMPT)
