Wiring diagram exterior lamps circuit (1 of 2)
1 2 3 GND
1239 5065 13 14 15 16 17 18 IGN 1 VOLT CHMSL
23 24 DATA BUS - DATA BUS +
5185 5186 TRAILER RIGHT HAND PARK SIG LEFT TURN SIG LAMP CTRL
5189 5190 TRAILER BACKUP LP SIG TRAILER REAR FOG LP SIG
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
BRN WIRE
CHMSL
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRL CTRL
EXTERIOR LAMPS CIRCUIT
GRY WIRE
HOT AT ALL TIMES
LEFT TRAILER PARK LAMP
LT BLU/WHT WIRE
LT GRN WIRE
ORG/ WIRE
PARK/ NEUTRAL SIG
PNK/BLK WIRE
PPL/WHT WIRE
REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL)
RED/BLK WIRE
RED/WHT WIRE
RR TURN SIG LP SPLY VOLT
TAN WIRE
TAN/BLK WIRE
TRAILER CONNECTOR
TRAILER CONNECTOR STATUS
TRAILER IGNITION RELAY
TRAILER LIGHTING CONTROL MODULE (CARGO COMPT)
TRAILER STOP LP SIG
TRLR 2 FUSE
TRLR EXP FUSE
TRLR MDL FUSE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Trailer tow circuit, with heavy duty trailer provisions -> EXTERIOR LAMPS CIRCUIT
Wiring diagram exterior lamps circuit (2 of 2)
22 8 17 PARK LAMP SPLY LEFT TRAILER RIGHT TRAILER
23 24 DATA BUS - DATA BUS +
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRL CTRL
EXTERIOR LAMPS CIRCUIT
HOT AT ALL TIMES
LEFT TRAILER STOP/ TURN SIGNAL LAMP RELAY
LT BLU/WHT WIRE
ORG/ WIRE
PRK LPS TRLR FUSE
REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL)
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RR TURN SIG LP SPLY VOLT
TAN WIRE
TAN/BLK WIRE
TRAILER CONNECTOR
TRAILER PARK LAMP RELAY
TRLR LT S/T LMP FUSE
TRLR RT S/T LMP FUSE
YEL WIRE
YEL/BLK WIRE
Go to component -> Trailer tow circuit, without heavy duty trailer provisions -> EXTERIOR LAMPS CIRCUIT
