Cadillac SRX II (2009-2012) drv htd seat back element ctrl pass htd seat back element ctrl Wiring diagram
This page shows the only wiring diagram for the component.drv htd seat back element ctrl pass htd seat back element ctrl, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv htd seat back element ctrl pass htd seat back element ctrl (1 of 1)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY POP-UP CONTROL SIGNAL
DK GRN WIRE
DRV HTD SEAT BACK ELEMENT CTRL PASS HTD SEAT BACK ELEMENT CTRL
DRV LO REF PASS LO REF
GMLAN SERIAL DATA
GND B+
GRY WIRE
HIGH IND
HOT AT ALL TIMES
HTD SEAT CUSHION ELEMENT SENS SIG PASS SEAT CUSHION ELEMENT SENS SIG
INFO DISPLAY MODULE
LEFT REAR BACK HEATED SEAT ELEMENT
LEFT REAR CUSHION HEATED SEAT ELEMENT
LOCAL INTERCONNECT NETWORK 10
LOGIC
LOW IND
LOW SPEED GMLAN SERIAL DATA
LT BLU WIRE
LT BLU/WHT WIRE
MED IND
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
PPL/WHT WIRE
RADIO (W/ NAVIGATION)
REAR FUSE BLOCK (LEFT REAR QUARTER PANEL)
REAR SEAT HEATING CONTROL MODULE
RED WIRE
RED/WHT WIRE
RIGHT REAR BACK HEATED SEAT ELEMENT
RIGHT REAR CUSHION HEATED SEAT ELEMENT
RR HTD SEAT FUSE
W/ REAR SEAT HEATER, TRIM SEAT LEATHER
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Rear heated seats circuit -> DRV HTD SEAT BACK ELEMENT CTRL PASS HTD SEAT BACK ELEMENT CTRL
