Cadillac SRX II (2009-2012) display ctrl sig Wiring diagram
This page shows the only wiring diagram for the component.display ctrl sig, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram display ctrl sig (1 of 1)
ANTI-LOCK BRAKES SYSTEM
BAT POS VOLT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CAMERA SIG - MICROPHONE SIG (-) PNK WIRE
CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA
COAX
CONSOLE)
DISPLAY CTRL SIG
DISPLAY CTRL SIG CAMERA SIG + MICROPHONE SIG (+) PNK WIRE
DISPLAY POS SIG
DISPLAYS FUSE
DK BLU WIRE
DK GRN WIRE
DRAIN WIRE
DRAIN WIRE NAV DISPLAY + RESET PNK
GRN/WHT WIRE
GROUND
HOT W/ LOGISTIC MODE RELAY 1 ENERGIZED
INFO DISPLAY MODULE (W/ NAVIGATION)
INSTRUMENT PANEL FUSE BLOCK (CENTER
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MOBILE TELEPHONE CONTROL MODULE
NAV TOUCH +
NAVIGATION ANTENNA SIGNAL SPLITTER
NAVIGATION SYSTEM
NCA WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
PPL NAV DISPLAY TOUCH - LF SPD SENS SIG
PPL/WHT WIRE
RADIO
RED/WHT WIRE
REMOTE ENABLE
RESET+
TAN/WHT WIRE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
VIDEO SYSTEM CIRCUIT
W/ ONSTAR
W/O ONSTAR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit (1 of 5) -> DISPLAY CTRL SIG
