Cadillac SRX II (2009-2012) cooling fan medium speed 1 relay Wiring diagram
This page shows the only wiring diagram for the component.cooling fan medium speed 1 relay, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cooling fan medium speed 1 relay (1 of 1)
BAT POS VOLT
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN 1 FUSE
COOLING FAN 2 FUSE
COOLING FAN DIODE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN LOW SPEED RESISTOR (FAN SHROUD)
COOLING FAN MEDIUM SPEED 1 RELAY
COOLING FAN MEDIUM SPEED RESISTOR (FAN SHROUD)
COOLING FAN MOTOR
COOLING FAN SPEED CONTROL 2 RELAY
COOLING FAN SPEED CONTROL RELAY
DATA BUS -
DK BLU WIRE
DK GRN WIRE
ECM_BATT FUSE
ENGINE COMPT)
ENGINE CONTROL MODULE (LEFT FRONT ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (REAR LEFT CYLINDER HEAD)
FAN RLY CTRL
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT COOLING FAN DIODE
LOW REF
LT BLU WIRE
POWERTRAIN RELAY
RED/WHT WIRE
RIGHT COOLING FAN DIODE
SENS SIG
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT FRONT
YEL WIRE
Go to component -> 3.0l vin y, cooling fan circuit -> COOLING FAN MEDIUM SPEED 1 RELAY
