Cadillac SRX II (2009-2012) bat pos volt rr damper low ref rr damper ctrl lr damper ctrl lr damper low ref Wiring diagram

ACCEL SENS SIG ACCEL SENS SIG RF ACCEL SENS SIG BAT POS VOLT RR DAMPER LOW REF RR DAMPER CTRL LR DAMPER CTRL LR DAMPER LOW REF BLK WIRE BLU/WHT WIRE BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH) BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ELECTRONIC SUSPENSION CONTROL MODULE (CARGO COMPT) GRY WIRE HOT W/ LOGISTIC MODE RELAY 2 ENERGIZED SADS MDL FUSE LEFT FRONT SHOCK ABSORBER ACTUATOR (LEFT FRONT STRUT) LEFT FRONT VERTICAL BODY ACCELERATION SENSOR (LEFT FRONT STRUT) LEFT FRONT VERTICAL WHEEL ACCELERATION SENSOR (LEFT FRONT WHEEL SPEED SENSOR) LEFT REAR SHOCK ABSORBER ACTUATOR (LEFT REAR STRUT) LF DAMPER LOW REF LF DAMPER CTRL RF DAMPER LOW REF RF DAMPER CTRL LF WHEEL LOW REF RF WHEEL LOW REF LOW REF LOW REF LOW REF LF WHEEL REF VOLT RF WHEEL REF VOLT REF VOLT REF VOLT REF VOLT LF WHEEL SIG LT BLU WIRE LT BLU/WHT WIRE LT GRN/BLK WIRE PNK/BLK WIRE PNK/WHT WIRE PPL/WHT WIRE REAR FUSE BLOCK (LEFT REAR QUARTER PANEL) REAR VERTICAL BODY ACCELERATION SENSOR (RIGHT UNDERCARRIAGE) RED/WHT WIRE RF WHEEL SIG RIGHT FRONT SHOCK ABSORBER ACTUATOR (RIGHT FRONT STRUT) RIGHT FRONT VERTICAL BODY ACCELERATION SENSOR (RIGHT FRONT STRUT) RIGHT FRONT VERTICAL WHEEL ACCELERATION SENSOR (RIGHT FRONT WHEEL RIGHT QUARTER PANEL RIGHT REAR SHOCK ABSORBER ACTUATOR (RIGHT REAR STRUT) SERIAL DATA SERIAL DATA - SERIAL DATA + SERIAL DATA + SERIAL DATA - SERIAL DATA BUS+ SERIAL DATA BUS+ SERIAL DATA BUS - SERIAL DATA BUS - SPEED SENSOR TAN WIRE TAN/BLK WIRE WHT WIRE YEL WIRE
