Cadillac SRX II (2009-2012) acc indicator control Wiring diagram
This page shows the only wiring diagram for the component.acc indicator control, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc indicator control (1 of 1)
2.8L
3.0L
ACC IND
ACC INDICATOR CONTROL
ACCESSORY VOLTAGE
AIR QUALITY SENSOR (AUTOMATIC A/C)
AUTOMATIC TRANSMISSION ASSEMBLY
BACKLIGHT DIMMING IND
BCM IGNITION MODE DATA SIG
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CONTROL SOLENOID VALVE ASSEMBLY
DK BLU WIRE
ECM RUN CRNK FUSE
ENGINE INSTRUMENT CONTROL CLUSTER MODULE (ECM)
FROM POWERTRAIN RELAY (DIAGRAM 1 OF 8)
GLOW PLUG/MAF FUSE
GRY/BLK WIRE
HEADLAMP HIGH BEAM RELAY
HEADLAMP LOW BEAM RELAY
IGN VOLTAGE
IGNITION
IGNITION MODE SWITCH
IGNITION SWITCH RUN SIGNAL
INL-STG COL LOCK FUSE
IPC MIL IGN FUSE
KEYLESS ENTRY CONTROL MODULE (RIGHT CARGO COMPT)
LEFT TRAILER STOP/TURN SIGNAL LAMP RELAY
LOW REFERENCE
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
MASS AIR FLOW SENSOR (2.8L)
PNK IGNITION VOLTAGE WIRE
PNK PNK WIRE
PNK WIRE
RELAY
RIGHT TRAILER STOP/TURN SIGNAL LAMP RELAY
RUN WIRE
SENS AIR QUAL FUSE
START IND
START IND CNTRL
STARTER FUSE
STARTER RELAY
STEERING COLUMN LOCK CONTROL MODULE
TCM RUN CRNK FUSE
TO REC RUN CRNK FUSE (DIAGRAM 4 OF 8)
TRANSMISSION CONTROL MODULE (TCM)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 8) -> ACC INDICATOR CONTROL
