Cadillac SRX II (2009-2012) 6 4 rf door ajar sw sig network 3 Wiring diagram
This page shows the only wiring diagram for the component.6 4 rf door ajar sw sig network 3, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 6 4 rf door ajar sw sig network 3 (1 of 1)
2 1 LR DOOR AJAR SW SIG NETWORK BUS 4
2 1 RR DOOR AJAR SW SIG NETWORK BUS 4
6 4 RF DOOR AJAR SW SIG NETWORK 3
6 4 RR DOOR AJAR SW SIG NETWORK 3
BLK WIRE
COMPUTER DATA LINES SYSTEM
COURTESY LAMP
DK GRN WIRE
DRIVER DOOR COURTESY
DRIVER DOOR LATCH ASSEMBLY
DRIVER WINDOW MOTOR (IN DRIVER'S DOOR)
GRY WIRE
GRY/BLK WIRE
INSTRUMENT PANEL COMPARTMENT LAMP
LAMP
LEFT REAR DOME/ READING LAMPS
LEFT REAR DOOR COURTESY
LEFT REAR DOOR LATCH ASSEMBLY
LEFT REAR WINDOW SWITCH
LEFT SUNSHADE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
ORG/ WIRE
OVERHEAD CONSOLE DOME/ READING LAMPS
PASSENGER AIR BAG DISABLE INDICATOR
PASSENGER DOOR COURTESY
PASSENGER DOOR LATCH ASSEMBLY
PASSENGER WINDOW MOTOR (IN FRONT PASSENGER DOOR)
PNK WIRE
RIGHT INSTRUMENT PANEL COURTESY LAMP
RIGHT QUARTER PANEL
RIGHT REAR DOME/ READING LAMPS
RIGHT REAR DOOR COURTESY
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
RIGHT SUNSHADE
TAN/WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> 6 4 RF DOOR AJAR SW SIG NETWORK 3
