Cadillac SRX II (2009-2012) 5 1 4 15 liftgate ajar sw sig dr lck ctrl dr lck unlck ctrl open/close sw Wiring diagram
This page shows the only wiring diagram for the component.5 1 4 15 liftgate ajar sw sig dr lck ctrl dr lck unlck ctrl open/close sw, which is found in the car Cadillac SRX II (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 5 1 4 15 liftgate ajar sw sig dr lck ctrl dr lck unlck ctrl open/close sw (1 of 1)
23 4 SERIAL DATA FUEL DR LCK RLY CTRL
5 1 4 15 LIFTGATE AJAR SW SIG DR LCK CTRL DR LCK UNLCK CTRL OPEN/CLOSE SW
5060 186 COMPUTER DATA LINES SYSTEM
8 24 LIFTGATE RLY HI CTRL HOOD AJAR SW SIG
BLK WIRE
BODY CONTROL MODULE (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DOOR LK SEC PCB RELAY
DOOR LOCKS SYSTEM
DRIVER INFORMATION CENTER DISPLAY INSTRUMENT PANEL CLUSTER (IPC)
FUEL DOOR RELEASE ACTUATOR RELAY
FUEL DOOR UNLATCH ACTUATOR
GRY WIRE
HOOD AJAR SWITCH (RADIATOR SUPPORT)
HOT AT ALL TIMES
L/GATE FUSE
LATCH RLY COIL CTRL
LIFTGATE LATCH ASSEMBLY
LIFTGATE RELEASE RELAY
LIFTGATE UNLATCH SWITCH
LOGIC
LT BLU WIRE
ORG/ WIRE
PNK/BLK WIRE
REAR BODY FUSE BLOCK (LEFT REAR QUARTER PANEL)
TAN WIRE
YEL WIRE
Go to component -> Liftgate release circuit -> 5 1 4 15 LIFTGATE AJAR SW SIG DR LCK CTRL DR LCK UNLCK CTRL OPEN/CLOSE SW
