Cadillac SRX I (2003-2009) w/o magnetic ride control Wiring diagram
This page shows the only wiring diagram for the component.w/o magnetic ride control, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o magnetic ride control (1 of 1)
10 12 HI SPEED SERIAL DATA + HI SPEED SERIAL DATA -
13 14 GMLAN SERIAL DATA GMLAN SERIAL DATA
4 3 GMLAN SERIAL DATA GMLAN SERIAL DATA
4 5 GMLAN SERIAL DATA GMLAN SERIAL DATA
BLK WIRE
BLK/WHT WIRE
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DK GRN WIRE
GMLAN SERIAL DATA
HI SPEED SERIAL DATA +
HI SPEED SERIAL DATA - HI SPEED SERIAL DATA + HI SPEED SERIAL DATA - 24 25
HIGH SPEED GMLAN SERIAL DATA BUS +
HVAC CONTROL MODULE (CENTER OF DASH, UNDER RADIO)
INSTRUMENT PANEL CLUSTER (IPC)
KW 2000 SERIAL DATA
LEFT HEADLAMP ASSEMBLY
LOW SPEED GMLAN SERIAL DATA
ONSTAR
RADIO
REAR SEAT AUDIO MODULE (REAR OF CENTER CONSOLE)
RED/WHT WIRE
RIGHT HEADLAMP ASSEMBLY
TAN WIRE
TAN/BLK WIRE
TERMINATOR RESISTOR (BEHIND RIGHT REAR QUARTER TRIM)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/ AUTOMATIC HEADLAMPS LEVELING
W/ MAGNETIC RIDE CONTROL
W/ ONSTAR
W/O MAGNETIC RIDE CONTROL
W/O ONSTAR
WHT/BLK WIRE
Go to component -> Computer data lines circuit (2 of 2) -> W/O MAGNETIC RIDE CONTROL
