Cadillac SRX I (2003-2009) w/o auto recirculating air, filter Wiring diagram
This page shows the only wiring diagram for the component.w/o auto recirculating air, filter, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o auto recirculating air, filter (1 of 1)
3.6L 4.6L
4.6L 3.6L
A/C CMPRSR CLUTCH RELAY CTRL
A/C REFRIG PRESS SENSOR
AMBIENT AIR TEMPERATURE SENSOR (AT FRONT CENTER OF ENGINE COMPT)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONDENSER
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECT SENSOR SIGNAL
FAN 1 FUSE
FAN 1 RELAY
FAN 2 RELAY
FAN-2 FUSE
GRY WIRE
HIGH SPEED FAN RELAY CTRL
HOT AT ALL TIMES
LOW REF
LOW REFERENCE
LOW SPEED FAN RELAY CTRL
LT BLU WIRE
LT GRN/BLK WIRE
MAIN RELAY CTRL
ORG/ WIRE
ORG/BLK WIRE
PWR/TRN RELAY
RIGHT COOLING FAN (EXCEPT 4.6L: BEHIND
S/P FAN RELAY
SERIAL DATA BUS-
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
W/ AUTO RECIRCULATING AIR, FILTER
W/O AUTO RECIRCULATING AIR, FILTER
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> W/O AUTO RECIRCULATING AIR, FILTER
