Cadillac SRX I (2003-2009) windshield wiper switch high signal Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper switch high signal, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper switch high signal (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES
DELAY SWITCH
DK GRN WIRE
FRNT WASHER FUSE
FRNT WASHER RELAY
FRNT WPR FUSE
FRONT WASHER RELAY CONTROL
GROUND
GRY WIRE
HIGH LOW INT
HOT AT ALL TIMES
IGN 1 VOLT
IGN MAIN RELAY
INSTRUMENT PANEL CLUSTER (IPC)
LEFT HEATED WASHER NOZZLE (AT LEFT SIDE OF HOOD)
LOW SPEED MLAN SERIAL DATA
LOW SPEED MLAN SERIAL DATA WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
LT BLU WIRE
LT GRN WIRE
MISC IGN FUSE
MIST OFF
ORG/ WIRE
PNK WIRE
PPL
RIGHT HEATED WASHER NOZZLE (AT RIGHT SIDE OF HOOD)
SYSTEM
TAN WIRE
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
WASHER FLUID LEVEL SWITCH (NEAR BASE OF WASHER FLUID RESERVOIR)
WASHER SWITCH
WHT WIRE
WINDSHIELD LOW HIGH WIPER MOTOR (LEFT REAR OF ENGINE COMPT) PARK SWITCH
WINDSHIELD WASHER FLUID PUMP (NEAR BASE OF WASHER FLUID RESERVOIR)
WINDSHIELD WASHER LIQUID LEVEL SIGNAL
WINDSHIELD WASHER SWITCH SIGNAL
WINDSHIELD WIPER HIGH SIGNAL SWITCH
WINDSHIELD WIPER SWITCH HIGH SIGNAL
WINDSHIELD WIPER SWITCH LOW SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/ WASHER SWITCH
WIPER SWITCH
WPR RELAY WIPER HI RELAY
YEL WIRE
Go to component -> Front wiper/washer & jet washer heater circuit -> WINDSHIELD WIPER SWITCH HIGH SIGNAL
