Cadillac SRX I (2003-2009) turn signal/multifunction switch) Wiring diagram
This page shows the only wiring diagram for the component.turn signal/multifunction switch), which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn signal/multifunction switch) (1 of 1)
12 8 11 HDLMP ON SIG SUPPLY VOLT SENSOR SIG
1317 5365 5365 1969 (BLUNT CUT)
19 23 25 18 FOG SW SIG HDLMP OFF SIG FLASH TO PASS SIGNAL HIGH BEAM SIG
5364 5364 1970 (BLUNT CUT)
AUTO
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (ON LOWER LEFT SIDE OF DASH)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK DK
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE COMPT)
FOG LAMP FUSE
FOG LAMPS IND
FOG RLY CTRL
FOGLAMP RELAY
FRONT FOG LAMP SWITCH
FTP
GMLAN SERIAL DATA
GRN WIRE
HI BEAM RELAY
HIGH BEAM IND
HOT AT ALL TIMES
HVAC CONTROL MODULE (CENTER OF DASH, UNDER RADIO)
INSTRUMENT PANEL LOGIC CLUSTER (IPC) SER DATA SERIAL DATA B+
LEFT FRONT FOG LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP ASSEMBLY
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LOW BEAM/HID RELAY
LOW REF
LT GRN WIRE
LT GRN/BLK WIRE
LT HIGH BEAM FUSE
LT LO BEAM FUSE (W/ HID) (W/O HID)
NCA WIRE
OFF PARK HEAD
ORG/ WIRE
PNK WIRE
PNK/WHT WIRE
PPL
RIGHT FRONT FOG LAMP
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
RT HI BEAM FUSE
RT LO BEAM FUSE
SERIAL DATA
SUNLOAD/AMBIENT LIGHT SENSOR (AT TOP CENTER OF DASH)
SUPPLY VOLT RLY CTRL
TAN WIRE
TAN/WHT WIRE
TURN SIGNAL/MULTIFUNCTION SWITCH)
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF
W/ HID W/O HID
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit -> TURN SIGNAL/MULTIFUNCTION SWITCH)
