Cadillac SRX I (2003-2009) trlr park lamps fuse Wiring diagram
This page shows the only wiring diagram for the component.trlr park lamps fuse, which is found in the car Cadillac SRX I (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trlr park lamps fuse (1 of 1)
APPROXIMATELY 35 CM (13.8 IN) FROM LEFT
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTER HIGH MOUNT STOP LAMP (CHMSL)
DETECTION SIGNAL LEFT TAIL LAMP OUTAGE
DK GRN WIRE
FROM LH POS PRK LAMP RELAY (DIAGRAM 1 OF 2)
GRN WIRE
LEFT HEADLAMP ASSEMBLY
LEFT HIGH BEAM HEADLAMP
LEFT MARKER LAMP
LEFT PARK LAMP
LEFT REAR FUSE BLOCK (NEAR LEFT SIDE OF REAR SEAT, UNDER CARPET)
LEFT STOP/TURN SIGNAL LAMP IND
LEFT TAIL LAMP ASSEMBLY
LH PRK LAMPS FUSE
LT BLU WIRE
PARK LIGHT
PPL
PPL PPL
PPL RIGHT TAIL LAMP OUTAGE DETECTION SIGNAL
RH PRK LAMPS FUSE
RIGHT HEADLAMP ASSEMBLY
RIGHT HIGH BEAM HEADLAMP
RIGHT MARKER LAMP
RIGHT PARK LAMP
RIGHT REAR FUSE BLOCK (NEAR RIGHT SIDE OF REAR SEAT, UNDER CARPET)
RIGHT STOP/TURN SIGNAL LAMP IND
RIGHT TAIL LAMP ASSEMBLY
SIDE MARKER
SIDE MARKER TAIL
SPARE RELAY
TAIL
TAIL LAMP DRIVE MODULE
TRAILER CONNECTOR
TRLR PARK LAMPS FUSE
UNDERHOOD FUSE BLOCK (AT RIGHT FRONT OF ENGINE COMPT)
W/ HID W/O HID
W/O HID W/ HID
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> TRLR PARK LAMPS FUSE
